Name: Open Body Ceiling Infrared PIR Motion Sensor Switch – 120° (AC 100–265V 200W LED) - klightdecor.in
SKU: SENS-PIR-OPEN-BODY
Price: 1200.00 INR
Availability: InStock

Open Body Ceiling Infrared PIR Motion Sensor Switch – 120° (AC 100–265V 200W LED)

A versatile circular open-body PIR motion sensor switch supporting up to 200W LED and 600W multi-load configurations. Features a 120-degree detection angle, 4–8m range, and convenient 4-stage gear-selectable timers (5s, 45s, 5m, 15m).

39 People watching this product now!

Description

Flexible Open-Body PIR Automation with Quick Gear Adjustments

This open-body circular infrared switch provides clean ceiling automation for residential and light-commercial areas. Featuring an exposed domed Fresnel lens with a wide 120-degree cone, it captures movement accurately up to 8 metres away. An integrated 4-position gear switch simplifies commissioning by providing fixed run-time intervals without guesswork.

Key Features:

Open-Body Circular Enclosure: Low-profile housing mounts cleanly to ceiling surfaces and electrical boxes.
4-Stage Selector Switch: Gear-adjustable delay times: 5 sec, 45 sec, 5 min, and 15 min.
High Efficiency Compatibility: Controls up to 200W of LED lighting or 600W total mixed lighting load.
Universal Voltage Operation: Operates smoothly across AC 100–265V lines.

Additional information

Weight	3 kg
Dimensions	250 × 180 × 100 mm
Input Voltage	50/60Hz, AC 100–265V
Load Capacity	LED ≤ 200W \| Multi-Load ≤ 600W
Induction Angle & Distance	120° / 4–8 meters
Installation Height	Max. 3.5 meters
Operating Temperature	-20°C to +45°C
